CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 35
HONDA GX120K1QX2/UT1QX2 ENGINE — CYLINDER BARREL ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
CYLINDER BARREL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 12000ZH7415 CYLINDER BARREL ASSY. (OIL ALERT) .........1................INCLUDES ITEMS W/ $
2 12000Z0S416 CYLINDER BARREL ASSY. (OIL ALERT) .........1................INCLUDES ITEMS W/ $
3 15510ZE1033 SWITCH ASSEMBLY, OIL LEVEL 1
3 15510ZE1033 SWITCH ASSEMBLY, OIL LEVEL ......................1................S/N 1111367 AND BELOW
3 35480Z0T003 SWITCH ASSEMBLY, OIL LEVEL ......................1................S/N 1111367 AND ABOVE
4 16510ZE1000 GOVERNOR ASSEMBLLY ................................1................INCLUDES ITEMS W/ #
5# 16511ZE1000 WEIGHT, GOVERNOR 2
6# 16512ZE1000 HOLDER, GOVERNOR WEIGHT 1
7# 16513ZE1000 PIN, GOVERNOR WEIGHT 2
8 16531ZE1000 SLIDER, GOVERNOR 1
9 16541ZE1000 SHAFT, GOVERNOR ARM 1
10 90131ZE1000 BOLT, DRAIN PLUG 2
11 90451ZE1000 WASHER, THRUST 6MM 1
12 90601ZE1000 WASHER, DRAIN PLUG 10.2MM 2
13 90602ZE1000 CLIP, GOVERNOR HOLDER 1
14$ 91001878003 BEARING, RADIAL BALL 62/22 1
15$ 91202ZE6003 OIL SEAL 22X35X6 1
15$ 91202ZE6013 OIL SEAL 22X35X6 1
16 91353671003 O- RING 13.5X1.5 (ARAI) 1
16 91353671004 O- RING 13.5X1.5 (ARAI) 1
17 9405010000 NUT, FLANGE 10MM 1
18 9410106800 WASHER, PLAIN 6MM 2
19 9425108000 PIN, LOCK 8MM 1
20 957010601200 BOLT, FLANGE 6X12 2
