CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 15
ENGINE ASSY., 4 HP HONDA (S/N CL0132684 AND BELOW)
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
21387
ENGINE, 4 HP. HONDA GX120K1QX2/UT1QX2 1
2
10036
HANDLE ASSY., CLUTCH ASSIST
1
3
0161 C
LOCK WASHER 5/16”
5
4
0300 B
FLAT WASHER 5/16”
11
5
1284
SCREW, HHC 3/8 -16 X 1-1/2”
2
6
0166 A
LOCK WASHER 3/8”
1
7
10136
FLAT WASHER 3/8”
1
8
0105
SCREW, HHC 5/16- 18 X 1-1/2”
2
9
10644
CLUTCH BRACKET
1
10
5277
SCREW, HHC 1/4- 20 X 1-1/2”
1
11
10229
SCREW, HHC 5/16 - 24 X 1"
2
12
10936
CABLE ASSY., HAND CLUTCH
1
13
10608
IDLER PULLEY
1
14
6014 C
NUT, HEX 5/16 X 24
1
15
10611
BELT (A21)
1
16
0730
SCREW, HHC 1/4- 20 X 1”
3
17
0181 B
LOCK WASHER 1/4”
5
18
10661
BELT GUARD ...................................................... 1 ......... SAFETY ITEM
19
21492
PULLEY
1
20
10909
SQUARE KEY 3/16 X 3/16 X 13/16”
1
21
10181
SCREW, HHC 5/16 - 24 X 1-1/4"
1
22
20979
CLUTCH LEVER
1
23
10610
PULLEY
1
24
0948
FLAT WASHER 1/4”
5
25
1512
CONTROL LEVER, HAND CLUTCH
1
26
20981
SHOE, BELT HAND CLUTCH
1
27
10450
SHS 10- 32 X 1/4”
1
28
0949
HEX NUT 1/4- 20
1
29
1733
WASHER, 1/2 X 1/32
1
30
13351
WASHER, FLAT USS 3/8 EXT. THK.
1
31
1672
SCREW, HHC 3/8 -24 X 1”
1
