CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 31
HONDA GX120K1QX2/UT1QX2 ENGINE — CRANKCASE COVER ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
CRANKCASE COVER ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
11300ZE0640
COVER ASSEMBLY, CRANKCASE (U- TYPE) .........1 .......INCLUDES ITEMS W/ %
1
11300ZE0641
COVER ASSEMBLY, CRANKCASE (U- TYPE) .........1 .......INCLUDES ITEMS W/ %
2
11381ZH7800
GASKET, CASE COVER
1
3
15600ZE1003
CAP ASSEMBLY, OIL FILLER ...................................1 .......INCLUDES ITEMS W/ #
3
15600Z0T810
CAP ASSEMBLY, OIL FILLER ...................................1 .......INCLUDES ITEMS W/ #
4
15600ZG4003
CAP ASSEMBLY, OIL FILLER ...................................1 .......INCLUDES ITEMS W/ $
4
15600Z0T820
CAP ASSEMBLY, OIL FILLER ...................................1 .......INCLUDES ITEMS W/ $
7#
15625ZE1003
GASKET, OIL FILLER CAP
1
7#
15625Z0T800
GASKET, OIL FILLER CAP
1
8$
15625ZE1003
GASKET, OIL FILLER CAP
1
8$
15625Z0T800
GASKET, OIL FILLER CAP
1
9
90015883000
BOLT, FLANGE 6X28
7
10%
91001878003
BEARING, RADIAL BALL
1
11% 91203ZE0003
OIL SEAL 22X41X6
1
11% 91203ZE0013
OIL SEAL 22X41X6
1
12
9430108140
PIN A, DOWEL 8X14
2
