mq600Td80 TRaSH pUmp• opeRaTion and paRTS manUal — Rev. #11 (10/10/11) — page 19
Figure 3 shows the location of the components and basic
components for the MQ600TD80 trash pump, The function
of each component or control is described below:
1.
pump end Jack Stand — Use this jack stand to level and
support the trash pump.
2. pump discharge port — Discharges water and debris
from the pump.
3. bearing Sight glass — Use this sight glass to determine
if oil is present. Oil must be visible within the sight glass
at all times.
4. mechanical Seal Sight glass — Use this sight glass to
determine if oil is present. Oil must be visible within the
sight glass at all times.
5. +12 vdC battery — Not provided with pump. See Table 1
for battery specifications.
6. Control box panel — Monitors engine functions and will
shut down the engine for low oil pressure, high coolant
temperature, alternator charge and V-belt failure.
7. muffler/guard — DO NOT touch the muffler when engine
is running. The muffler can become extremely hot, causing
severe burns. NEVER run the pump with the muffler guard
removed.
8. lifting bail — When lifting of the trash pump by crane is
required, use this lifting bail. Note: this lifting bail is balanced
for a fully configured trash pump; removal of any trash pump
components will unbalance the lifting bail.
9. oil bath Cleaner — Prevents dirt and any foreign debris
from entering the engine. Service this unit as recommended
in the maintenance section of this manual.
10. Tow end Jack Stand — Use this jack stand to level and
support the trash pump.
11. brake Coupler — This device will activate the hydraulic
braking system of the pump's trailer in the event the pump's
trailer becomes detached from the towing vehicle.
12. Tow Hitch Coupler — Requires a 2.0-inch ball hitch or a
3-inch pintle.
13. Safety Chain — Always attach safety chain to the towing
vehicle. NEVER! tow the trash pump with the safety chain
unattached.
14. documentation box — Contains documentation for the
pump and engine.
15. engine Throttle lever — Controls the speed of the engine.
For load conditions (pumping water) ALWAYS run the engine
at full speed.
cOMpOnents
16. oil Filler — Fill as recommended in the maintenance
section of this manual.
17. engine (diesel) — This pump uses a Deutz D914 air-
cooled, 4-stroke diesel engine. See the Deutz Operation
manual supplied with the trash pump for additional engine
information.
18. Fuel gauge/Filler port — Read top of gauge to determine
fuel level. Re-fuel using only recommended types of diesel
fuels (see Deutz Operation Manual). DO NOT top off fuel,
wipe up any spilled fuel immediately.
19. Chock blocks — Place these blocks (not included as part
of the trash pump package) under each trailer wheel to
prevent rolling.
20. Trailer lights — Before towing trash pump, make sure that
both trailer lights are functioning correctly. NEVER tow the
trash pump if these lights are not working.
21. pump Shaft guards — To prevent injury to hands and
fingers these two guard covers (one each side of pump
housing) are to remain in place at all times when the pump
is in use.
22. dipstick — Read this gauge to determine the level oil in the
engine crankcase. Fill with only recommended type oil as
referenced in the maintenance section of this manual.
23. Fuel Filters — This pump design incorporates the use of
four fuel filters, maintain these filters as recommended in
the maintenance section of this manual.
24. Fuel Water Separator — Removes water from the
fuel system. Inspect and clean as recommended in the
maintenance section of this manual.
25. Support Tubes — These tubes protect the fuel tank from
being damaged when the pump frame is lying on a flat
surface.
26. Fuel Tank/drain plug — The fuel tank is part of the frame
(sides). It holds 40 gallons (51 liters) of diesel fuel. Remove
this drain plug to drain the fuel tank.
27. pump intake port — Intakes water and debris from the
source.
28. Fill Cap — Remove this cap to prime the pump with
water.
29. Clean-out Cover — Remove this cover to clean and remove
foreign debris from the trash pump.
30. accessories — Hoses, strainers and clamps are the
required accessory components for normal operation of
this trash pump. Contact your nearest Multiquip dealer for
information on the component.
