mq600Td80 TRaSH pUmp• opeRaTion and paRTS manUal — Rev. #11 (10/10/11) — page 13
speciFicatiOns
Table 1. engine Specifications
Engine Make Deutz
Engine Model D914
Engine Type Air Cooled 4-Stroke Diesel
Number Of Cylinders 4
Bore/Stroke (F4L913) 102/125 mm
Bore/Stroke (F4L914/D914) 102/132 mm
Continuous Engine HP (F4L913) 60.0 HP @1,900 RPM*
Continuous Engine HP (F4L914 68.3 HP @1,900 RPM*
Continuous Engine HP (D914) 63.0 HP @2000 RPM*
Combustion Method Direct Fuel Injection
Oil Capacity 9.5 gal/2.5 liters
Fuel Type Diesel
Fuel Tank Capacity 40 gal/51.0 liters
Starting Method Electric Start
Battery
+12 VDC @ 650 amps w/reserve capacity 160
amp min.
Battery Dimensions (L x W x H) 13"" x 6-3/4"" x 8-3/8""
*Maximum Engine HP (intermittent)@ 2,500 RPM = 80 HP
Table 2. pump Specifications
Maximum Pumping Capacity 1600 gpm (6,055 lpm)
Maximum Suction Lift* 25 FT. (7.6 meters)
Maximum Total Head 150 FT. (45.7 meters)
Maximum Pressure 64.9 psi
Maximum Solids 3 in. (76 mm)
Suction and Discharge Diameter 6 in. (152 mm)
Dimensions (LxWxH) 63.0 HP @2000 RPM*
Trailer Mounted 80 x 39 x 49 in.
(203 x 99 x124 cm.) 9.5 gal/2.5 liters
Weight (No Fuel) 3,060 lbs. (1,388 kg.)
* Based on pump operating at sea level. Maximum suction lift will be less at higher altitudes.
SoUnd meaSURemenTS
The required sound specifications, per Appendix 1, paragraph 1.7.4.f of the EC-Machine Regulations, are defined as follows:
The sound pressure level at the operator's location (L) = 87 dB (A)
The sound power level (L) = 97 dB (A)
These sound values are determine according to ISO 3744 for the sound power level (L) and ISO 6081 for the sound
pressure level (L) at the operator's location.
The sound measurements were obtained with the unit operation on pavement at nominal speed.
