MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 65
L70V6GF1R1AA — ELECTRIC DEVICE ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 464457460 BATTERY CORD (-) 400L 1
2 464457470 BATTERY CORD (+) 550L 1
3 466217900 CRADLE, BATTERY 1
4 456447590 RUBBER PLATE (E) 28X240X5 1
5 456447600 RUBBER PLATE 50X240X10 2
6 001221020 BOLT 10X20 T 2
7 030210250 WASHER, LOCK M10 2
8 955010090 BATTERY 55B24L 1
9 955300490 BATTERY TERMINAL (-) 1
10 955300470 TERMINAL COVER (-) 1
11 955300480 BATTERY TERMINAL (+) 1
12 955300460 TERMINAL COVER (+) 1
13 466021010 COVER, BATTERY(G) 1
13 466021020 COVER, BATTERY(OR) 1
13 466021030 COVER, BATTERY (W) 1
14 466461520 FIXED PLATE, BATTERY COVER 2
15 001220825 BOLT 8X25 T 4
16 030208200 WASHER, LOCK M8 4
17 464457390 BATTERY BOLT 2
18 022710809 NYLON NUT M8 2
19 031108160 WASHER, FLAT M8 2
20 464343740 HOLDER, BATTERY 1
24 466462030 WIRE CP 1
26 454010020 CLAMP TC-100 3
28 955300400 BUZZER (EBL) 1
41 955300680 STARTER SWITCH ASSY 1
41-1 955000010 KEY (STARTER SWITCH) 1
44 10519878570 HARNESS (C), WIRE 1
