MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 53
L70V6GF1R1AA — CRANKSHAFT AND CAMSHAFT ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 71421014580 CAMSHAFT ASSY. 1
6 11421014200 TAPPET 2
7 11421014300 ROLLER TAPPET ASSY. 1
12 11421014400 PUSH ROD ASSY. 2
13 71421021740 CRANKSHAFT (D) ASSY. 1
21 11428821220 NUT 1
22 11439921590 FLYWHEEL (DE) ASSY. ............................. 1 ................ INCLUDES ITEM W/ *
25 * 11436221600 RING GEAR 1
26 11429921550 FLYWHEEL WASHER 1
27 22512040120 KEY 4X12 1
45 71421028510 BALANCER SHAFT ASSY. 1
62 26106080202 BOLT M 8X20 PLATED 1
63 16031014550 WASHER 1
64 22512070360 KEY 7X36 RR 1
65 24101062030 BEARING 2
