MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 45
L70V6GF1R1AA — CYLINDER BLOCK ASSY
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
11421001010
CYLINDER BLOCK ASSY.
1
5
11439501330
CYLINDER HEAD GASKET ASSY.
1
8
11435001800
COVER, STARTER
1
9
26106100122
BOLT M10X20 PLATED
2
11
11439901380
O- RING
1
12
11429901800
SHIM SET
1
23
11429901830
COVER (FO PUMP)
1
24
11425001841
GASKET
1
25
22312040080
PIN 4X8 STRAIGHT
2
26
23875020000
PLUG PT1/4 STEEL
1
27
11429901600
PIN, 8X12
2
28
26226060182
STUD M 6X18 PLATED
1
29
26226060222
STUD M 6X22 PLATED
2
30
26366060002
NUT M6
3
31
11439901410
CRANKCASE GASKET
1
32
11421001460
CRANKCASE COVER D ............................ 1 ................ INCLUDES ITEMS W/ *
35
*
11435002100
MAIN BEARING US=STD.
1
35
11435002200
MAIN BEARING US=0.25
1
35
11435002210
MAIN BEARING US=0.50
1
37
11429935150
L.O. INLET PIPE
1
38
26106080352
BOLT M 8X35 PLATED
15
39
11429901690
PLUG M16
2
40
11469901760
OIL GAUGE CAP, W/LUB ........................... 2 ................ INCLUDES ITEMS W/ $
42$
24311000180
O- RING
2
43
22190160002
SEAL WASHER 16S
2
44
11429902030
RETAINER
1
45
11435002113
BALL BEARING
1
46
16011002220
OIL SEAL
1
47
16011002220
OIL SEAL
1
48
24162152116
NEEDLE BEARING
1
49
26106080122
BOLT M 8X12 PLATED
1
52
23876010000
PLUG PT 1/8
1
