MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 35
BASE AND ENGINE ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 466119780 BASE 1
2 914410029 ENGINE, L70V6GF1R1AA 1
3 001221040 BOLT 10X40 T 4
4 030210250 WASHER, LOCK M10 4
5 031110160 WASHER, FLAT M10 4
6 466347750 BELT COVER 1
7 001220825 BOLT 8X25 T 4
8 030208200 WASHER, LOCK M8 4
11 466461470 SPACER 1
12 466347700 CLUTCH ASSY/CHM03/W.FAN 1
13 22512070360 KEY 7X36 RR 1
14 466461490 WASHER, CLUTCH 1
15 001220830 BOLT 8X30 T 1
16 030208200 WASHER, LOCK M8 1
17 466217870 DUST-PROOF COVER 1
18 092006010 FLAT HEAD SCREW 6X10 4
19 466347740 DUST-PROOF SPONGE (OUT) 1
20 466119740 BELT COVER (OUT) 1
21 001521054 SOCKET HEAD BOLT 10X70 T 4
35 466119720 RUBBER COVER (GUARD FRAME) 1
36 466461500 PLATE, COVER 1
37 001220830 BOLT 8X30 T 3
38 030208200 WASHER, LOCK M8 3
39 031108160 WASHER, FLAT M8 3
40 022710809 NYLON NUT M8 3
41 2556390111 UNION 1
42 2556380103 DRAIN HOSE 1
43 0091720000 HOSE CLAMP 2
44 0211140020 GASKET 2
45 0401140030 PLUG 1
