MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 37
NO. PART NO. PART NAME QTY. REMARKS
46 464457380 DRAIN JOINT 1
47 001220820 BOLT 8X20 T 1
48 030208200 SW M8 1
49 454010020 CLAMP TC-100 1
51 466119730 GUARD HOOK 1
52 001221230 BOLT 12X30 T 4
53 030212300 WASHER, LOCK M12 4
59 459455560 JOINT, OIL DRAIN 1
60 22190160002 WASHER, SEAL 16S 1
61 070200363 V-BELT B-36 GREEN /HDPF536 1
62 2344600213 RETURN SPRING 1
63 2067550101 CLAMP COMPL 1
64 031105080 WASHER, FLAT M5 1
65 020406040 NUT M6, H = 4.2 1
66 959406800 NUT M6 (SPECIAL - L10) 1
BASE AND ENGINE ASSY
