MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 47
L70V6GF1R1AA — CYLINDER HEAD ASSY
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
11421001200
CYLINDER HEAD A BOLT
2
2
11421001210
CYLINDER HEAD B BOLT
2
3
11421011020
CYLINDER HEAD ASSY.
1
7
11421011100
INTAKE VALVE
1
8
11421011110
EXHAUST VALVE
1
9
11421011120
VALVE SPRING
2
10
11421011180
SPRING RETAINER
2
11
11421011930
COTTER ASSY.
2
13
11421011250
SUPPORT ASSY. ROCKER .......................1 ................ INCLUDES ITEMS W/ #
14#
11421011260
ROCKER ARM SUPPORT
1
15#
11421011280
C TYPE RETAINING PIN
2
16#
11421011650
INTAKE ARM ASSY.
1
INCLUDES ITEMS W/ %
18%
11429911240
ADJUSTING SCREW
1
19%
26856060002
LOCK NUT 6
1
20#
11421011660
EXHAUST ARM ASSY. .............................. 1 ................ INCLUDES ITEMS W/ $
22$
11429911240
ADJUSTING SCREW
1
23$
26856060002
LOCK NUT 6
1
24
11435011340
VALVE STEM SEAL
2
25
11477111461
NOZZLE GASKET
1
26
11429511470
NOZZLE SPACER
1
27
10501011490
VALVE CAP
2
28
11429911600
VALVE SPRING WASHER
2
29
11421011900
NOZZLE RETAINER
1
30
22351040008
SPRING PIN 4X8
1
31
26106060402
BOLT M6X40 PLATED
2
32
26226060552
STUD M 6X55
2
33
26366060002
NUT M6
2
34
11421011310
BONNET GASKET
1
35
11421011950
BONNET HEAD ASSY. .............................. 1 ................ INCLUDES ITEMS W/
*
37
*
11421003590
DECOMP SHAFT ASSY.
1
40
*
11429903640
DECOMP SPRING
1
42
*
22312030160
PARALLEL PIN 3X16
1
45
26106060552
BOLT M 6X55 PLATED
1
