MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 59
L70V6GF1R1AA — COOLING AND STARTING DEVICE ASSY
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
11429945220
TANK GROMMET
5
2
11421045260
SIDE COVER B (13)
1
3
11421045270
SIDE COVER A (13)
1
4
11421045300
TOP COVER, BLACK (13)
1
5
11421045310
DAMPER
1
6
11439945320
SEAL RUBBER
1
7
11439945340
CYLINDER COLLAR COVER
5
8
11421045350
TOP COVER SPACER
1
9
26106060082
BOLT M 6X8 PLATED
4
10
26106060202
BOLT M 6X20 PLATED
4
11
26226060852
BOLT STUD 6X85
1
12
26366060002
NUT M 6
1
13
11421045100
FAN CASE (SILVER) (17)
1
14
11429945300
CUSHION RUBBER
4
15
11429945310
FAN CASE COLLAR
4
16
11429945330
FAN CASE SEAL
1
17
11429945350
FAN CASE BOLT
4
19
11439976250
RECOIL STARTER (D) ASSY. .................... 1 ................ INCLUDES ITEMS W/
*
20
*
11439976510
STARTER CASE
1
21
*
11439976520
RECOIL REEL
1
22
*
11439976530
RATCHET
1
23
*
11439976540
SPIRAL SPRING
1
24
*
11439976550
RATCHET COVER
1
25
*
11439976560
SPRING
1
26
*
11439976570
RETURN SPRING
1
27
*
11439976580
SCREW
1
28
*
11439976620
STARTER KNOB
1
29
*
11439976630
STARTER ROPE
1
30
11439976590
STARTER PULLEY
1
31
26106060082
BOLT M 6 X 8 PLATED
4
32
26106060122
BOLT M 6 X 12 PLATED
3
