MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 57
L70V6GF1R1AA — LUB. OIL PUMP AND GOVERNOR ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 11425032010 LUB. OIL PUMP ASSY. 1
7 11429932070 LUB. OIL PUMP COVER 1
8 11429932570 O- RING COVER 1
9 22312030160 PARALLEL PIN 3X16 1
10 26106060122 BOLT M 6X12 PLATED 3
11 11429935110 LUBE OIL FILTER COMPLETE ................. 1 ................ INCLUDES ITEMS W/ *
13 * 24341000224 O- RING 1A S- 22.4 1
14 26106060162 BOLT M 6X16 PLATED 1
15 11421061500 LEVER ASSY. ............................................ 1 ................ INCLUDES ITEMS W/ #
27# 22322030200 TAPER PIN 3X20 1
32# 22322030200 TAPER PIN 3X20 1
35 71421061700 GOVERNOR ASSY. ................................... 1 ................ INCLUDES ITEMS W/ +
36+ 11421061290 GOVERNOR WEIGHT ASSY. 1
41 11429961600 OIL SEAL 1
42 11477061610 THRUST WASHER 1
43 11429961190 GOVERNOR WASHER 1
44 11477161810 PLAIN WASHER 14 1
45 11477161830 PLATE 1
46 11429561940 NUT 1
47 11477166600 FUEL LIMITER ASSY. 1
48 11477166690 NUT M14 1
49 13521061090 LEAD 1
50 22451060000 WIRE 0.6 1
51 11477061520 NEEDLE BEARING 2
52 11425266051 REGULATOR HANDLE 1
54 18336066110 REGULATOR BRACKET 1
55 11429966250 RETURN SPRING 1
56 11429966440 ADJUSTING BOLT 1
57 10522566990 SCREW 1
58 26106060142 BOLT M 6X14 PLATED 1
59 26106060202 BOLT M 6X20 PLATED 1
60 26757060002 LOCK NUT M6 PLATED 1
61 11421066010 REGULATOR SPRING 1
62 11429966200 RETURN SPRING 1
63 11477161890 PROTECTOR COMPLETE ........................ 1 ................ INCLUDES ITEMS W/%
65% 11477161960 SPACER 1
66% 24311000180 O- RING 1A P- 18.0 1
