MVH206D PLATE COMPACTOR • OPERATION AND PARTS MANUAL — REV. #1 (10/25/11) — PAGE 61
L70V6GF1R1AA — FUEL INJECTION PUMP ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 71421051100 FUEL INJECTION PUMP ASSY ................ 1 ................ INCLUDES ITEMS W/ *
2 * 10554651020 GASKET 1
3 * 11425051080 PLATE 1
4 * 11421051200 FUEL INJECTION PUMP BODY 1
10 11425051160 SPRING 1
11 * 11421051300 DELIVERY VALVE ASSY. 1
12 * 12455051350 DELIVERY GASKET 1
13 * 11425051600 CONTROL LEVER ASSY. 1
14 * 11425051640 SPRING SEAT A 1
15 * 11425051650 SPRING SEAT B 1
16 * 22351020006 SPRING PIN 2X6 2
17 * 22351030008 SPRING PIN 3X8 1
18 71421053100 FUEL INJECTOR ....................................... 1 ................ INCLUDES ITEMS W/ $
19$ 11421053000 NOZZLE ASSY. 1
20$ 11421053100 NOZZLE HOLDER ASSY. .......................... 1 ................ INCLUDES ITEMS W/ #
21# 11421053080 NOZZLE NUT 1
23# 11421053330 PIN 1
24# 11421053120 NOZZLE SPRING 1
25# 11421053130 SPRING SEAT 1
26# 11421053140 VALVE SPACER ASSY. 1
27# 11421053410 SHIM (T=1.00) 1
27 11421053420 SHIM (T=1.05) 1
27 11421053430 SHIM (T=1.10) 1
27 11421053440 SHIM (T=1.15) 1
27 11421053450 SHIM (T=1.20) 1
27 11421053460 SHIM (T=1.25) 1
27 11421053470 SHIM (T=1.30) 1
27 11421053480 SHIM (T=1.35) 1
27 11421053490 SHIM (T=1.40) 1
27 11421053500 SHIM (T=1.45) 1
27 11421053510 SHIM (T=1.50) 1
27 11421053520 SHIM (T=1.55) 1
27 11421053530 SHIM (T=1.60) 1
27 11421053540 SHIM (T=1.65) 1
27 11421053550 SHIM (T=1.70) 1
27 11421053560 SHIM (T=1.75) 1
27 11421053570 SHIM (T=1.80) 1
27 11421053580 SHIM (T=1.85) 1
27 11421053590 SHIM (T=1.90) 1
27 11421053600 SHIM (T=1.95) 1
27 11421053610 SHIM (T=2.00) 1
