MTS Advantage™ Screw Action Grips Operation 23
Grip Faces for 100 N (22.5 lbf) and 2000 N (450 lbf) Grips
The faces for the 100 N (22.5 lbf) and the 2000 N (450 lbf) Advantage
Screw Action Grips are compatible and the same as the ones used on MTS
Pneumatic Grips. The 25 x 25 mm (1.0 x 1.0 in) size is preferred for the 100
N grip; the 38 x 58 mm (1.5 x 2.28 in) size is preferred for the 2000 N grip.
12.5 mm x 25 mm
(0.5 in x 1 in)
25 mm x 25 mm
(1 in x 1 in)
F ACE S URFACE P ART N UMBER O BSOLETE P/N *
* Obsolete part numbers are associated with older grips. Current part
numbers are direct replacements.
Rubber (smooth-EPDM) †
† Rubber grip faces are for use only at room temperature.
056-163-825 38.00579
F ACE S URFACE P ART N UMBER O BSOLETE P/N *
* Obsolete part numbers are associated with older grips. Current part
numbers are direct replacements.
Smooth 056-163-801 38.00601
Corrugated 056-163-802 38.00602
Serrated 056-163-803 38.00603
Diamond Tip 056-163-804 38.00604
Rubber (matte) †
† Rubber grip faces are for use only at room temperature.
056-163-805 none
Rubber (corrugated) 056-163-806 none
Rubber (smooth-EPDM) † 056-163-807 38.00424
Line Contact r=4.75mm 056-163-808 none
Line Contact w/Rubber
Opposite
† r=4.75mm
056-163-826 none
Line Contact w/Rubber
Opposite
† r=2.5mm
056-163-829 38.00544
