MTS Advantage Screw Action Grip User Manual
Page 17
MTS Advantage™ Screw Action Grips
Installation
17
Installation
This section discusses the installation of the MTS Advantage Screw Action
Grips. Two procedures are provided for installing the grips:
•
One for servohydraulic applications
•
One for electromechanical applications
Contents
Install Grips on Servohydraulic Systems 17
Install Grips on Electromechanical Systems 19
Install Grips on Servohydraulic Systems
Follow the steps outlined in the next several pages to install the grip on your
test system.
Grip installation is inherently dangerous because it takes place within
the crush zone of the force train, when full hydraulic pressure is applied
to the system and actuator movement is required.
Serious personal injury and equipment damage can occur.
Take every precaution to avoid unexpected actuator movement and to avoid
dropping the grip.
WARNING
