Page 15
MTS Advantage™ Screw Action Grips
Introduction
15
Grip faces
Six types of face surfaces are available for use with these grips:
•
Corrugated for gripping smooth specimens
•
Serrated for gripping soft material
•
Rubber coated for extra gripping protection for thin specimens
•
Diamond tipped for more aggressive gripping needs
•
Grab test for gripping fabric specimens
•
Line contact for gripping rubber, latex, and cable sheath
MTS Advantage Screw Action Grips Specifications
The following tables list the specifications for the MTS Advantage Screw
Action Grips and for the specimens that are to be tested. Specifications are
defined at room temperature.
M
ODEL
M
ONOTONIC
T
ENSION
C
APACITY
R
ATING
N
LBF
100 N
100
25
2000 N
2000
450
5000 N
5000
1125
10,000 N
10,000
2250
M
ODEL
S
PECIMEN
T
HICKNESS
(
MAXIMUM
)
G
RIP
H
EIGHT
G
RIP
W
IDTH
(
DOES
NOT
INCLUDE
PISTON
SCREW
)
G
RIP
WEIGHT
P
ART
N
UMBER
MM
IN
MM
IN
MM
IN
KG
LBS
100 N
12
0.50
78
3
100
3.9
0.36
0.80
055-426-701
2000 N
19
0.75
95
3.9
125
4.9
0.95
2.1
055-426-801
5000 N
25
1.00
123
4.8
170
6.7
2.1
4.6
055-426-901
10,000 N
25
1.00
123
4.8
170
6.7
4.9
10.8
100-030-185
