MTS Advantage™ Screw Action Grips Introduction 16
The temperature matrix specifies the temperature range at which the grip can
be used depending on the various components that comprise the grip when
configured for testing. For example, a grip (aluminum body) with a silicon
puck and lubricated piston screw would have a temperature range of -40 to
150 ºC (-40 to 300 ºF).
S IZE S OCKET H EAD C AP S CREW
*
* Each grip order includes two socket head cap screws for grip
installation. The optional pin adapters listed require the use of these
screws.
P ART N UMBER
15 mm M6 x 1 055-425-901
30 mm M12 x 1.25 055-425-701
45 mm M12 x 1.25 055-426-001
5/8 in M6 x 1 055-425-801
1-1/4 in M6 x 1 100-021-398
1-1/4 in M12 x 1.25 055-425-601
G RIP C OMPONENT T EMPERATURE R ANGE
ºC ºF
Aluminum (body, puck)
-129 – 150
*
* Recommended constant maximum temperature. Higher maximum
temperatures (200 ºC, 400 ºF) can be used, but only for limited
periods of time (2 hours maximum).
-200 – 300
*
Lubricant †
† Applies to lubricant supplied with the grip. Other lubricants are
available for additional temperature ranges; contact MTS for
additional information.
-40 – 150 ‡
‡ Although the actual maximum temperature specification for these
components is higher, the testing environment of the grip is limited
by the aluminum body.
-40 – 300 ‡
Nylon (puck) -129 – 77 -200 – 170
Silicon (puck)
-51 – 150
‡
-60 – 300
‡
Rubber (face) Ambient Ambient
