EXPLODED VIEW AND PARTS LIST
J5
Bearing, 17mm X 40mm X 12mm Ball (6203-2NSE)
2
137711
J6 Shaft,
Blade
100/101
1
158222
J7 Flange,
2-3/8
Inner
1
137737
J8
Flange, 2-3/8 Outer
1
135830
J9 Nut,
5/8-18
Hex
1
135848
J10
Pulley, 6J19 X 5/8 Bore
1
158199
J11
Key, 3/16 x 3/16 x 1 1/8 Square
1
150344
J12
Screw, 5/16-18 X 3/8 Socket Head Set, Cup Point
2
157083
J13
Bumper, 1/2 Dia Rubber
1
152674
J14
Screw, 5/16-18 X 1 Hex Head Cap
4
151743
J15
Washer, 5/16 SAE Flat
4
151754
J16
Washer, 5/16 Split Lock
4
151747
J17
Nut, 5/16-18 Hex
4
101196
J18
Screw, 5/16-18 x 2 1/2 Hex Head Cap, Full Thread
1
151748
J19 Pivot,
Blade
Guard
1
153208
J20
Washer, 3/8 SAE Flat
2
150923
J21 Wingnut,
5/16-18
Nylock
1
151746
J22
Strap, Motor Adjustment
1
152673
J23
Screw, 3/8-16 X 3 1/2 Hex Head Full Thread
1
153147
K-M
Assembly, DC Table, MK-101
1
158477
K Guide
Bars
-
-
K1
Bar, 3/4 X 32 Guide, 101
1
134759
K2
Cover, Guide Bar, 120
° X 35”
1 158403
K3
Spacer, Guide Bar Cover, 101
2
152393
K4
Screw, 5/16-18 X 1 Hex Head Cap
2
151743
K5
Washer, 5/16 Split Lock
2
151747
K6
Washer, 5/16 SAE Flat
2
151754
L Tables
-
-
L1
Table, 100/101
1
157660
L2
Washer, 5/16 SAE Flat
2
151754
L3
Washer, 5/16 Split Lock
2
151747
L4
Screw, 5/16-18 X 1 Hex Head Cap
2
151743
M Assembly,
Roller
Wheel
1
151756
M1
Bracket, Roller Wheel
1
154021
M2
Wheel,
Roller
1
151799
M3
Screw, 1/4-20 X 1 1/2 Hex Head Cap
1
151914
M4
Washer, 1/4 SAE Flat
1
151915
M5
Nut, 1/4-20 Hex
1
151893
