Unpacking, transport, jcs stand and assembly, Jcs stand: key components for set up – MK Diamond MK-101 JCS Rental User Manual
Page 12
MK-101 Home Depot Rental Revision 04/05, Effective Date April 21, 2005
Page 12
UNPACKING, TRANSPORT, JCS STAND and ASSEMBLY
JCS STAND: Key Components for Set Up
Note: Familiarize with the following components before proceeding to SET UP.
Blue Knob
Green Knob
Handle
Cross
Member
Wheel Lock
Front Legs
Cutting Head
Handle
Table Clip
Air Springs
Front Legs
Safety Arm
