Exploded view and parts list – MK Diamond MK-101 JCS Rental User Manual
Page 45
MK-101 Home Depot Rental
Revision 04/05, Effective Date April 21, 2005
Page 45
EXPLODED VIEW AND PARTS LIST
E1
Stop, 10” Cutting Head
1
157728
E2
Screw, Hex Head, 1/4-20 X 1 1/4
1
157145
E3
Washer, 1/4 Split Lock
1
152591
E4
Sheet, Cutting Head Stop Instruction
1
157728-IS
F-J
Assembly, DC Cutting Head, PL-101R, Home Depot, Orange
1
158478-HD
F Belt
Guards
-
-
F1
Belt Guard, MK-101, Orange
Insert, 3/8-16 AVK
1
2
158319-OR
158193
F2
Bracket, Inner Belt Guard, 100/101
1
158611
F3
Screw, Hex Head, 1/4-20 x 3/4
3
152370
F4
Screw, Hex Head, 1/4-20 x 1
1
152676
F5
Washer, 1/4 Split Lock
4
152591
F6
Washer, 1/4 SAE Flat
4
151915
F7
Belt, 260J6 Micro-V
1
158194
G
Assembly, Blade Guard, MK-101R, Orange
1
155513
G1
Blade Guard, MK-101Rental, Orange
1 155303
G2 Tube,
Water
2
155389
G3
Screw, Set, 5/16-18 X 1/2
3
152607
G4
Elbow, 1/8 MNPT X 1/4 BARB 90
° Brass
1 154652
H Motors
-
-
-
Assembly, Motor, 1-1/2HP\120v\60Hz\L5-15P\30A SBox
1
159709-TL
H1
Motor, 1-1/2HP\120v\60Hz, for 30A switchbox, with L5-15P
1
159627-TL
H2
Pulley, 6J17 X 5/8 Bore
1
158214
H3
Key, 3/16 x 3/16 x 1-1/8 Square
1
150344
H4
Screw, Set, 5/16-18 X 3/8
2
157083
H5
Label, Warning most motor... 2 3/4 X 2 7/16
1
155672
H6
Label, Caution, GFCI, 1 X 2 1/8
1
155678
H7
Label, Caution, 5 Amp Max., 1 X 2-1/8
1
154822
H8
Label, Warning, Read Owner’s Manual, 1-3/4 X 3-3/8
1
155806
H9
Label, MK Service Info., 2 1/8 X 1-13/16
1
155038
H10 Label,
HD
Checklist
1
155231
H11
Box, Top Entry, 30A Switch
1
159487
H12
Cover, 30A Switch Box
1
159539
H13
Lever, Actuator, 30A Switch Box
1
159540
H14
Plate, Mounting, 30A Switch
2
159489
H15
Lever, On/Off, 30A Switch Box
1
159490
H16
Bushing, Nylon, 30A Switch Box
1
158799
H17
Seal, Urethane, 30A Switch Box
1
159492
H18
Gasket, 30A Switch Box
1
159491
H19 Switch,
30A/2HP/120V/DPST
1
159488
H20 Connector,
LTF11
Cord
1
159582
H21
Screw, 6-32 X 5/16 Flat Head Phillips Machine
6
159493
H22
Screw, 10-24 X 1/4 Pan Head Phillips Machine
1
159494
H23
Screw, 6-32 X 5/8 Pan Head Phillips Machine
4
157393
H24
Screw, 10-24 X 5/16 Slotted Hex Washer Head Grounding
1
159597
H25
Washer, #10 SAE Flat
1
154369
H26
Washer, #10 Lock, Internal Teeth
2
158336
H27
Terminal, 16-14 X #10 Ring, Non-insulated
1
154540
H28
Label, Home Depot Tool Rental
1
160602
J Assembly,
Cutting
Head
1
158191-OR
J1
Cutting Head, DC, 101, Orange
1
158224-OR
J2
Pin, Blade Shaft Lock
1
158200
J3
Spring, Blade Guard Lock
1
158201
J4 E-Ring,
1/4
Retaining
1
158202
