Exploded view and parts list – MK Diamond MK-101 Tracker User Manual
Page 40
MK-101 TRACKER
Revision 06/05, Effective Date June 07, 2005
Page 40
EXPLODED VIEW AND PARTS LIST
F-J
Cutting Head Assemblies
- - -
-
Assembly, DC Cutting Head, MK-101
1-1/2hp\120V60Hz\1PH
1 158478
-0-
F Belt
Guards
F1
Belt Guard, MK-101
1
158319-01
*
F2
Bracket, Inner Belt Guard, 100/101
1
158611
*
F3
Screw, 1/4-20 x 3/4 Hex Head Cap
3
152370
*
F4
Screw, 1/4-20 x 1 Hex Head Cap
1
152676
*
F5
Washer, 1/4 Split Lock
4
152591
*
F6
Washer, 1/4 SAE Flat
4
151915
*
F7
Belt, 260J6 Micro-V
1
158194
*
G
Blade Guard Assemblies
- - -
-
Assembly, Blade Guard, MK-101/115
G1-4 1
152582 -0-
G1
Blade Guard, 101/115
1 153659
*
G2 Tube,
Water
2
155389
*
G3
Screw, 5/16-18 X 1/2 Socket Head Set
3
152607
*
G4
Elbow, 1/8 MNPT X 1/4 BARB 90
° Brass
1 154652 *
H Motors
- - -
H1
Motor, 1-1/2HP\120V\60Hz
1
151473
*
H2
Pulley, 6J17 X 5/8 Bore
1
158214
*
H3
Key, 3/16 x 3/16 x 1-1/8 Square
1
150344
*
H4
Screw, 5/16-18 X 3/8 Socket Head Set, Cup Point
2
157083
*
H5
Label, Warning most motor..., 2 3/4 X 2 7/16
1
155672
*
H6
Label, Caution, GFCI, 1 X 2 1/8
1
155678
*
H7
Label, Caution, 5 Amp Max., 1 X 2-1/8
1
154822
*
H8
Label, Warning, Read Owner’s Manual, 1-3/4 X 3-3/8
1
155806
*
H9
Label, MK Service Info., 2 1/8 X 1-13/16
1
155038
*
J
Cutting Head Subassemblies
- - -
-
Subassembly, DC Cutting Head, 100/101
1 158191
-0-
J1
Cutting Head, DC, 100/101, MK Red
1
158224
*
J2
Pin, Blade Shaft Lock
1
158200
*
J3
Spring, Blade Guard Lock
1
158201
*
J4
E-Ring, 1/4 Retaining
1
158202
*
J5
Bearing, 17mm X 40mm X 12mm Ball (6203-2NSE)
2
137711
*
J6
Shaft, Blade 100/101
1
158222
*
J7
Flange, 2-3/8 Inner
1
137737
*
J8
Flange, 2-3/8 Outer
1
135830
*
J9 Nut,
5/8-18
Hex
1
135848
*
J10
Pulley, 6J19 X 5/8 Bore
1
158199
*
J11
Key, 3/16 x 3/16 x 1 1/8 Square
1
150344
*
J12
Screw, 5/16-18 X 3/8 Socket Head Set, Cup Point
2
157083
*
J13
Bumper, 1/2 Dia Rubber
1
152674
*
J14
Screw, 5/16-18 X 1 Hex Head Cap
4
151743
*
J15
Washer, 5/16 SAE Flat
4
151754
*
J16
Washer, 5/16 Split Lock
4
151747
*
J17
Nut, 5/16-18 Hex
4
101196
*
J18
J18A
Screw, 5/16-18 x 2 1/2 Hex Head Cap, Full Thread
Bolt, 5/16-18 x 2 1/2 Carriage
1
1
151748
152675
*
J19 Pivot,
Blade
Guard
1
153208
*
J20
Washer, 3/8 SAE Flat
2
150923
*
J21 Wingnut,
5/16-18
Nylock
1
151746
*
