MK-101 TRACKER
Revision 06/05, Effective Date June 07, 2005
Page 25
SETUP, ADJUSTMENT and OPERATION
Ensure water is not forced into the motor casing when cleaning.
(K)
Clean the Movable Cutting
Table Roller Wheel Frame
Support
(J)
Clean the Movable Cutting
Table Guide Bar
(L)
Clean the remainder of the
MK-101 TRACKER
Roller Wheel
Frame Support
Clean
Guide Bar
(N)
Clean the Movable Cutting
Table Guide Wheels
(M)
Clean the Movable Cutting
Table Roller Wheels
Roller
Wheels
Guide Wheel
