MK-370EXP SAW PARTS LIST
ITEM. DESCRIPTION QTY. PART #
1 FLANGE, OUTER, 2-3/8 2 135830
2 NUT,HEX, 5/8 - 18 1 135848
3 KNOB, DAVIES, 5/16 - 18 X 1 2 151681
4 NUT, WING, NYLK, 5/16 - 18 1 151746
5 WASHER, LOCK, SPLIT, 5/16 1 151747
6 BOLT, HEX HD TAP, 5/16 - 18 X 2 - 1/2 1 151748
7 NUT, HEX, 10-24 2 151749
8 SCREW, FIL HD, SLT, #10 - 24 X 3/4 1 151750
9 SCREW, FIL HD, SLT, #10 - 24 X 1 1 151751
10 SCREW, SHOULDER, 1/2 X 1/2 2 151753
11 WASHER, FLAT, SAE, 5/16 3 151754
12 NUT, HEX, 1/4 - 20 1 1515893
13 SCREW SHOULDER 5/16 X 5/8 1 152137
14 SCREW HEX HD, 1/4 - 20 X 3/4 1 152370
15 ELBOW, 1/8 MNPT X 1/4 BARB 90DEG 1 154652
16 CASTING, BLD GRD, 7 INCH BLADE (COMP) 1 154811
17 MTR, ELECT, 7.4 AMP 120V 1 156428-R
18 SCREW, FLAT HD 10 -32 X 5/8" 4 157554
19 CASTING, COMMON PART, CTTG HD-C 1 159937
20 CASTING, MTR MOUNT, COMMON-COMP 1 159941
