33

When installing the Retaining Nut, do not “cross-thread" and DO NOT over tighten the screw.

DIAMOND BLADE CHANGE-OUT

(B)

Remove Retaining Nut and

Outer Flange

(A)

Open the Outer Blade

(C)

Remove Diamond Blade

from Blade Shaft

(E)

Install the Retaining Nut

and Outer Flange and then

tighten using the Blade and

Shaft Wrenches

(D)

Install the Diamond Blade

onto Blade Shaft

(F)

Verify the Blade is seated on

the Blade Shaft and direction

of rotation is correct

(G)

Close the Outer Blade

MK-370EXP SAW

MAINTENANCE

NOTE:
