Card File Handler
Operation
Editing drive sets
28 1.1 EN
L
Removing a GDC parameter set file
S
How to remove a GDC parameter set file from a drive set:
1. Select the drive set from which you want to remove the GDC parameter set file
from the archive tree.
2. Go to the Dialog area and click the icon to the right of the GDC parameter set
file text field.
3. You will be asked if you really want to remove the GDC parameter set file. Confirm
this question with OK.
3.3.4 Adding/removing user data
Adding user data
After a DDS binary file has been added to the drive set, you can add an *.lc9 file including
motion profiles or cam profile data to the drive set (option).
S
How to add user data to a drive set:
1. Select the drive set to which you want to add the user data from the archive tree.
2. Go to the Dialog area and click the icon to the right of the User data text field.
• The function can only be activated if you have already added a DDS binary file
to the drive set.
3. Go to the Open user data dialog box, select the corresponding *.lc9 file and click
Open.
Note!
Ensure that the user data match the program because this will not be checked
automatically.
In the Drive PLC Developer Studio, you can use the CAM Support to add cam
profile data to your project. For detailed information, please read the
documentation for the Drive PLC Developer Studio.
