Editing drive sets
24 1.1 EN
L
3.3 Editing drive sets
What is a drive set?
A drive set contains all data required for a specific target system, i.e.:
C the DDS binary file (*.bin) including the compiled IEC 61131 program
- and as an option -
C the GDC parameter set file (*.gdc) including the parameter settings (codes) of the
target system,
C additional user data, e.g. cam profiles or motion profiles.
X
Tip!
You can add a comment to each drive set and provide that the card module
executes a Reset (origin) before the data is downloaded to the target system.
Reset (origin) resets all variables of the target system, including the RETAIN and
PERSISTENT variables to their initialisation value. The user program is deleted and
the control is reset to its original state.
Organisation of the drive sets
Just like the SmartMedia card of the card module, each archive card may contain up to 16
drive sets called "0" ... "F" in the default setting.
C The colour of the drive set icon depends on the usage of the drive set:
–
Drive set is free.
– Drive set is used.
– Drive set is incomplete or invalid usage.
C The settings for a drive set selected from the archive tree can be entered in the Dialog
area.
C Each drive set has a separate sub-folder on the file level in which the files for the target
system are stored.
