Card File Handler
Operation
Organising cards
3.2.3 Importing data from a SmartMedia card
This function is used to import drive sets from a SmartMedia card of the card module into
an archive card.
C All valid drive sets of the SmartMedia card will be imported into the selected archive
card.
C The drive sets will be automatically marked with the program names.
S
How to import data from a SmartMedia card:
1. Insert the SmartMedia card into the card reader connected to your PC.
2. Select the card into which the drive sets of the SmartMedia card are to be imported
from the archive tree.
3. Go to the toolbar and click the icon or select the command FileCardImport
from SmartMedia card.
4. Go to the SmartMedia card --> Archive card X dialog box and select the letter for the
drive to which the card reader has been assigned.
5. Click Load.
Note!
• All drive sets of the selected archive card will be overwritten during the data
import!
• This function requires a Card reader for SmartMedia memory cards to be
connected to the USB interface of your PC!
Supported SmartMedia card readers
(E 33)
• Never remove the SmartMedia card during read/write access from the
card reader. This could result in loss of data or damage the SmartMedia card!
Note!
After the data import, the Card File Handler automatically executes the "eject"
function in the card reader to ensure that the SmartMedia card can be removed
without loss of data from the card reader.
For another read/write access to the SmartMedia card, remove the SmartMedia
card and reinsert it into the card reader. After this, it can be identified by the
Card File Handler.
