EMF2179IB communication module (DeviceNet)
Lenze codes and DeviceNet objects
Implemented DeviceNet objects
5
5.7
5.7.2

5.7-6 EDSDEN EN 02/2006
Instance 0:
Attribute Service(s) Description Data type Value
1 GET Revision UINT 0002
hex
Instance 1:
Attribute Service(s) Description Data type Value
1 GET MAC ID USINT 0 - 63
2 GET Baud rate USINT 0 - 2
3 GET / SET BOI BOOL 0/1
4 GET Bus-off counter USINT 0 - 255
5 GET Allocation
information
Struct of
Allocation
choice byte
BYTE 0 – 63
Master’s MAC ID USINT 0 – 63
Services:
Service code Name Description
0E
hex
Get_Attribute_Single Reading of an attribute
10
hex
Set_Attribute_Single Writing of an attribute
4B
hex
Allocate_Master/Slave_Connection_Set Demands the application of
“Predefined Master/Slave Connection
Set”
4C
hex
Release_Group_2_Identifier_Set Connections via “Predefined
Master/Slave Connection Set” are
deleted
DeviceNet Class (03
hex
)
