EMF2179IB communication module (DeviceNet)

Commissioning

Possible settings via DIP switch

5

5.5

5.5.1

5.5-1

EDSDEN EN 02/2006

5.5

Commissioning

5.5.1

Possible settings via DIP switch

Note!

The Lenze setting for all switches is OFF.
The device address and baud rate set via DIP switch will only be

active after a renewed mains connection.
Switch S9 is ineffective.

The following settings can be easily carried out via the front DIP switches of

the communication module:
ƒ Software compatibility of 2175 DeviceNet / 2179 communication

module with S10

ƒ Device address with S1 - S6
ƒ Baud rate with S7 / S8
