EMF2179IB communication module (DeviceNet)
Commissioning
Preparing the basic device for communication
5
5.5
5.5.4

5.5-7 EDSDEN EN 02/2006
5.5.4 Preparing the basic device for communication

Note!
During operation, the change of a communication module to
another basic device can lead to undefined operating states.
1. Set the Lenze parameter operating mode (C0001) to ”3” to enable the
controller via the communication module. This can be made using the
keypad or directly via DeviceNet.
Lenze codes in the controller and communication module can be read and
written via the vendor-specific class 110.
ƒ Example: write C0001 = 3
– Class: 0x6E
– Instance: 0x1
– Attribute: 0x1
– Service code: set single attribute
– Data sent: 0x7530 (30 000
dec
)
For further examples, see ( 5.7-17).
2. Terminal 28 (controller enable) is always active and must be set to
HIGH level during DeviceNet operation (see Operating Instructions for
the controller).
– Otherwise, the controller cannot be enabled.
– With 821X, 8200vector and 822X, the QSP (quick stop) function is
always active. If QSP is assigned to an input terminal (Lenze setting:
not assigned), this terminal must be at HIGH level during DeviceNet
operation (see Operating Instructions for the controller).
82XX / 8200 vector frequency
inverter
