Preface and general information
1-1
L
_^ONMObk
1 Preface and general information
1.1 About these Operating Instructions
•
These Operating Instructions are intended for safety-relevant operations on and with the
2102 fieldbus module. They contain safety information which must be observed.
•
All personnel working on and with the 2102 fieldbus module must have these Operating
Instructions available and observe the information and notes relevant for them.
•
The Operating Instructions must always be complete and perfectly readable.
These Operating Instructions inform about the most important technical data and the installation of
the 2102 fieldbus module. They are only valid in combination with the Operating Instructions of the
corresponding controller.
1.1.1 Terminology used
Controller In the following, the term ”controller” is used for ”93XX servo inverters” or ”82XX frequency inverters”.
Drive system In the following the term ”drive system” is used for drive systems with fieldbus modules and other Lenze
drive components.
Fieldbus module In the following text the term ”fieldbus module” is used for ”fieldbus module type 2102 RS232, RS485,
optical fibre”.
Cxxx/y Subcode y of code Cxxx (e.g. C0410/3 = subcode 3 of code C0410)
L-Cxxx/y Lenze code
Xk/y Terminal strip Xk/terminal y (e.g. X3/28 = terminal 28 on terminal strip X3)
( ^xx-yyy) Cross reference (chapter - page)
1.1.2 What is new?
Ident. no. edition of Important Contents
391 845 08/1996 1st edition
394 448 02/1997 replaces 391 845 • extended by 2102.V904, 2102.V905, 2102.V906
• Chapter 6.3
• Editorially reviewed
404 788 11/1998 replaces 394 448 Format change to DIN A4
417 816 10/2000 replaces 404 788 Adaptation to 8200 vector (all chapters)
474 677 10/2003 replaces 417 816 Change of company name
1.2 Packing list
Packing list Important
• 1 2102 fieldbus module with housing (enclosure IP20)
• 1 M3 fixing screw
After the delivery has received, check immediately whether the items
supplied match the accompanying papers. Lenze does not accept any
• 1 M3 fixing screw
• 1 two-pole male connector for voltage supply
• 1 Short Instructions
supplied match the accompanying papers. Lenze does not accept any
liability for deficiencies claimed subsequently.
Claim • 1 Short Instructions Claim
• visible transport damage immediately to the forwarder
• visible deficiencies/incompleteness immediately to your Lenze • visible deficiencies/incompleteness immediately to your Lenze
representative.
