Appendix
8-5
L
_^ONMObk
Code Note Name
C0135 * Controller control word Bit 820X 821X, 8200 vector, 822X C0135 Controller control word
(parameter channel) for:
• 820X
• 821X
0 JOG1, JOG2, JOG3
0
= C0046 active
1 = JOG1 (C0037) active 821X
• 8200 vector
• 822X
1
1 = JOG1 (C0037) active
2 = JOG2 (C0038) active
3 = JOG3 (C0039) active
JOG1, JOG2, JOG3
(P2102)
2 CW/CCW (CW rotation/CCW rotation)
0
= CW rotation
1 = CCW rotation
3 QSP (quick stop)
0
= QSP not active
1 = QSP active
4 Reserved RFG stop (stop of the ramp function
generator)
0 = RFG stop not active
1 = RFG stop active
5 Reserved RFG zero (deceleration along the T
if
ramp C0013)
0 = RFG zero not active
1 = RFG zero active
6 Reserved UP function for motor potentiometer
0
= UP not active
1 = UP active
7 Reserved DOWN function for motor
potentiometer
0 = DOWN not active
1 = DOWN active
8 Reserved
9 Ctrl. inhibit (controller inhibit)
0
= No controller inhibit
1 = Controller inhibit
10 Reserved
11 Reserved TRIP reset
0⇒1
Edge from 0 to 1 causes TRIP reset
12 PAR (parameter set changeover)
0
⇒ 1 (= parameter set 2)
1 ⇒ 0 (= parameter set 1)
13 Reserved
14 DC brake (DC injection brake)
0
= DCB not active
1 = DCB active
15 Reserved
The control word controls the controller. It compresses and summarizes control commands in bit commands.
LECOM format: VH
