Parameter setting
6-6
L
BA2102EN
6.5 Special notes for 821X, 822X, 824X controllers
Relative setpoint selection C0127 (process and parameter channel)
•
Absolute setpoint selection
A setpoint is input as absolute Hz value via the process and the parameter channel:
Process channel: Setpoint absolute ±24000 ≙ 480 Hz
Parameter channel: C046 absolute in Hz
C141 no influence
•
Normalized setpoint selection
A setpoint is input as absolute C0011 value via the process and parameter channel:
Process channel: Setpoint absolute ±2 14
≙ C011 (fd
max
)
Parameter channel: C046 only display absolute in Hz
C141 ±100.00% ≙ C011 (fd
max
)
Code Name Note
C0127 Frequency setpoint selection format
(P2102)
0 Absolute setpoint selection
1 Normalized setpoint selection
LECOM format: VD
6.6 Special notes when using 8200 vector controllers
The digital and analog input and output signals can be configured freely (see Operating Instructions
vector; codes C0410, C0412, C0417 and C0421).
