Appendix
8-8
L
_^ONMObk
Code Note Name
C0150 * Controller status word
(parameter channel) for: Bit 820X 821X, 822X 8200 vector
Free configuration via C0417 (see (parameter channel) for:
• 820X
Free configuration via C0417 (see
Operating Instructions for 8200
vector) 820X
• 821X
• 8200 vector
• 822X
0 Reserved Actual parameter set
0
= PS 1 active
1 = PS 2 active
FREE 0 (free access)
(P2102)
1 IMP (pulse inhibit)
0
= Pulses for power stage enabled
1 = Pulses for power stage inhibited
2 I
max
(current limit reached)
0 = Current limit not reached
1 = Current limit reached
FREE 2 (free access)
3 Reserved f
d
= f
dset
(Act. frequency =
Frequency setpoint)
0 = f
d
<> f
dset
1 = f
d
= f
dset
FREE 3 (free access)
4 f
d
= f
dset
(Act. frequency =
Frequency setpoint)
0
= f
d
<> f
dset
1 = f
d
= f
dset
RFG on = RFG off
(RFG input = RFG output)
0 = RFG in < > RFG out
1 = RFG on = RFG off
FREE 4 (free access)
5 Q
min
(f
d ≤
f
dQmin
)
0 = Q
min
not active
1 = Q
min
active
FREE 5 (free access)
6 f
d
= 0 (act. frequency = 0)
0 = f
d
< > 0
1 = f
d
= 0
7 Ctrl. inhibit (controller inhibit)
0
= No controller inhibit
1 = Controller inhibit
8 - 11 Controller status
0
= No error
1 = Error
Controller status
0 = Unit initialisation
1 = Autostart lock
3 = Operation inhibited
4 = Flying-restart circuit active
5 = DC injection braking active
6 = Operation enable
7 = Message active (dynamically
set pulse inhibit, e.g. at OU)
8 = Fault active
Controller status
0 = Unit initialisation
1 = Autostart lock
3 = Operation inhibited
6 = Operation enable
7 = Message active (dynamically
set pulse inhibit, e.g. at OU)
8 = Fault active
9 = Power off
12 Overtemperature warning ( J
max
- 10 °C)
0 = No controller inhibit
1 = Controller inhibit
Warning
0 = No warning
1 = Warning
13 U
Gmax
(DC-bus overvoltage)
0 = No overvoltage
1 = Overvoltage
Message
0 = No message
1 = Message
14 Direction of rotation
0
= CW rotation
1 = CCW rotation
FREE 14 (free access)
15 Ready for operation (no error, overvoltage or undervoltage)
0
= Not ready for operation
1 = Ready for operation
FREE 15 (free access)
The status word contains the most important status information in a compressed form.
LECOM format: VH
