Appendix
8-6
L
_^ONMObk
Code Note Name
C0135 * Controller control word
(parameter channel) for: Bit General structure 1xx1
Speed control
4xx1
Torque control (parameter channel) for:
• 93XX general
• 93XX default setting
0 FREE 0 (free access) JOG1, JOG2, JOG3
0 = C0141 (speed setpoint in %
of n
max
) active
FREE 0 (free access)
93XX default setting
for
– C0005 = 1xx1
– C0005 = 4xx1
1 FREE 1 (free access)
of n
max
) active
1 = JOG1 (C0039.1) active
2 = JOG2 (C0039.2) active
3 = JOG3 (C0039.3) active
FREE 1 (free access)
C0005 = 4xx1
(P2102) 2 FREE 2 (free access) (P2102)
3 QSP (quick stop)
0
= QSP not active
1 = QSP active
4 (free access) NSET-RFG-STOP (stop of the ramp function generator)
0
= NSET-RFG-STOP not active
1 = NSET-RFG-STOP active
5 (free access) NSET-FRG-0 (deceleration at the Tif ramp C0013)
0
= NSET-RFG-O not active
1 = NSET-RFG-O active
6 FREE 6 (free access)
7 FREE 7 (free access)
8 Reserved
9 Ctrl. inhibit (controller inhibit)
0
= No controller inhibit
1 = Controller inhibit
10 Reserved
11 TRIP reset
0⇒1
Edge from 0 to 1 causes TRIP reset
12 (free access) PAR*1 (parameter set changeover)
0
= PS 2/4
1 = PS 1/3)
13 (free access) PAR-SET
Activate parameter set changeover
14 (free access) T
i1
, T
i2
, T
i3
0 = C0012/C0013 active
1 = T
i1
, (C0102.1/C0103.1)
active
JOG1, JOG2, JOG3
0 = No active JOG
1 = JOG1 (C0039.1) active
2 = JOG2 (C0039.2) active
15 (free access)
active
2 = T
i2
, (C0102.1/C0103.1)
active
3 = T
i3
, (C0102.1/C0103.1)
active
2 JOG2 (C0039.2) active
3 = JOG3 (C0039.3) active
The control word controls the controller. It includes the control commands in a compressed bit format.
LECOM format: VH
