8.4 SysLibDPV1Hilscher.lib function library
The SysLibDPV1Hilscher.lib function library supports the acyclic PROFIBUS DPV1 - class 1
write and read services for data transfer between the master and the slaves. The data is
addressed within the slave stations via slot and index (for this see the PROFIBUS-DP
standard).
If the target system is supported, the following function blocks are available:
DPV1_Read / DPV1_ReadEx function block
( 51)
DPV1_Write / DPV1_WriteEx function block
( 52)
8.4.1 V1State structure
This structure is used by the blocks of the SysLibDPV1Hilscher.lib library with the State
output variable. It describes the status of the order.
Description of the components
TYPE V1State :
(NotEnabled := 0, InvalidParam, Started, Done, DoneWithError );
END_TYPE
Identifier/data type Meaning/possible settings
NotEnabled := 0 The function block is not active.
InvalidParam Invalid input parameter
Started The function block has started processing.
Done The function block has completed processing.
DoneWithError The function block has aborted processing with an error.
