Control technology | PROFIBUS communication manual
Function libraries
BusDiag.lib function library
8.1.2 DiagGetState function block
If a station available on the bus reports an error, its specific diagnostics information can be
read with the DiagGetState block.
DiagGetState must be called explicitly with the device number and the bus member ID
(station address).
Inputs (VAR_INPUT)
Outputs (VAR_OUTPUT)
Identifier/data type Meaning/possible settings
ENABLE
BOOL
The function block is activated in an edge-controlled manner:
• Positive edge (TRUE) = diagnostics information is detected and READY is set to
TRUE.
DRIVERNAME
POINTER TO
STRING
Always set to ’0’: The diagnostics order is passed to all available drivers.
DEVICENUMBER
INT
Identification of the bus which is managed by this module (driver).
• The instance results from the PLC configuration. The first PROFIBUS station
attached corresponds to the instance 0, the second to the instance 1 etc.
• For a second MC-PBM communication card, for instance, there is a second
GetBusState instance with another %MByy address. In order to obtain extended
diagnostics with the DiagGetState function block ( 41) , you must call the block
with Instance := 1.
BUSMEMBERID
DWORD
Station address of the PROFIBUS station for which the diagnostics information is to
be requested.
Identifier/data type Meaning/possible settings
READY
BOOL
FALSE: The diagnostics order is processed.
TRUE: Processing of the diagnostics order is completed.
STATE
INT
When READY = TRUE, STATE indicates the current status of the block by one of the
following values. These values are assigned to global constants. The constants are
stored in the BusDiag.lib function library.
Value = -1 Invalid input parameter
• Constant NDSTATE_INVALID_INPUTPARAM
Value = 0 Diagnostics information is not released.
• Constant NDSTATE_NOTENABLED
Value = 1 Diagnostics information is requested.
• Constant NDSTATE_GETDIAG_INFO
Value = 2 Diagnostics information is available.
• Constant NDSTATE_DIAGINFO_AVAILABLE
Value = 3 No diagnostics information available (error when reading data).
• Constant NDSTATE_DIAGINFO_NOTAVAILABLE
