Commissioning
Quick commissioning
General configuration settings
6
l
81 EDS84DG752 EN 4.0
Possible settings with P2 "Speed"
With P2, a motor speed setpoint in percent of the rated speed in C00011 can be preset in
10 steps (JOG fixed setpoint). The JOG setpoint is only activated if input DI1 is set in
"Local mode".
P2 Setting
Description 0 1 2 3 4 5 6 7 8 9
Motor speed in percent of the rated speed setting
C00011 [%] 0 11 22 33 44 55 66 77 88 100
Possible settings with P3 "Ramp"
P3 Setting
Description 0 1 2 3 4 5 6 7 8 9
Acceleration or deceleration time of the motor in
seconds [s] 0.1 0.5 1 2 5 10 20 30 60 120
Possible settings with P1
Potentiometer P1 can be accessed after the cover has been removed. In order to ensure the
degree of protection of the controller, the cover has to be screwed in again after the
settings have been made.
During operation, P1 can be used to steplessly set the motor speed in percent of the rated
speed in C00011 if no JOG fixed setpoint P2 is active via DI1.
P1 Setting
Description 0 ... 9
Motor speed in percent of the rated speed C00011 [%] 0 ... 100
