Technical data
Rated data
Operation at rated mains voltage 400 V
l
34
EDS84DG752 EN 4.0
Fuses and cable cross−sections
ƒ
Point−to−point connection − direct wiring of the mains voltage − typical fusing
Operation
Type
Installation according to EN 60204−1
1)
Installation according
to UL
2)
FI
3)
L1, L2, L3 − laying system
L1, L2, L3
B2
C
F
[A]
[A]
[mm
2
]
[mm
2
]
[mm
2
]
[A]
[AWG]
[mA]
E84DGDVB3714
C 16
16
2.5
−
−
15
12
³ 30
E84DGDVB5514
C 16
16
2.5
−
−
15
12
³ 30
E84DGDVB7514
C 16
16
2.5
−
−
15
12
³ 30
E84DGDVB1124
C 16
16
2.5
−
−
15
12
³ 30
E84DGDVB1524
C 16
16
2.5
−
−
15
12
³ 30
E84DGDVB2224
C 16
16
2.5
−
−
15
12
³ 300
E84DGDVB3024
C 16
16
2.5
−
−
15
12
³ 300
E84DGDVB4024
C20
20
4.0
−
−
20
12
³ 300
E84DGDVB5524
C20
20
4.0
−
−
20
12
³ 300
E84DGDVB7524
C 20
20
4.0
−
−
20
12
³ 300
ƒ
Multiple connection − loop−through connection of the mains voltage − maximum
fusing
Operation
Type
Installation according to EN 60204−1
1)
Installation according
to UL
2)
FI
3)
L1, L2, L3 − laying system
L1, L2, L3
B2
C
F
[A]
[A]
[mm
2
]
[mm
2
]
[mm
2
]
[A]
[AWG]
[mA]
E84DGDVB3714
C 32
32
6.0
−
−
15
12
³ 30
E84DGDVB5514
C 32
32
6.0
−
−
15
12
³ 30
E84DGDVB7514
C 32
32
6.0
−
−
15
12
³ 30
E84DGDVB1124
C 32
32
6.0
−
−
15
12
³ 30
E84DGDVB1524
C 32
32
6.0
−
−
15
12
³ 30
E84DGDVB2224
C 32
32
6.0
−
−
25
10
³ 300
E84DGDVB3024
C 32
32
6.0
−
−
25
10
³ 300
E84DGDVB4024
C 50
50
16.0
−
−
50
6
³ 300
E84DGDVB5524
C 50
50
16.0
−
−
50
6
³ 300
E84DGDVB7524
C 50
50
16.0
−
−
50
6
³ 300
1)
These values are recommendations only. Other dimensioning values/laying systems are possible (e.g. according to
VDE 0298−4). The cable cross−sections apply under the following conditions: Use of PVC−insulated copper cables,
conductor temperature < 70 °C, ambient temperature < 45°C, no bundling of cables or cores, three loaded cores.
2)
Only use UL−approved cables, fuses and fuse holders.
UL fuse: voltage
³ 500 V, tripping characteristic e.g. "CC". The cable cross−sections apply under the following
conditions: conductor temperature < 75 °C, ambient temperature < 45°C.
3)
Universal−current sensitive earth−leakage circuit breaker, short−time delayed
Circuit breaker
Fuse of gG/gL utilisation category or semiconductor fuses of gRL utilisation category
Fuse
Observe national and regional regulations
