Product description
Type code
The type codes
3
l
24 EDS84DG752 EN 4.0
8400 motec Set

E84DV B x xxx x S x x x 2 x x
Product range
Inverter Drives 8400 motec
Version
B = not relevant
Design
M = motor−mounted device
W = wall−mounted device
Power e.g.
152 = 15 x 10
2 W = 1.5 kW
Voltage class
4 = 400/480 V, 3/PE AC (also for IT systems)
Control element
S = standard (DIP switches/ potentiometer/X70)
Communication (fieldbus)
N = NO BUS (without fieldbus)
A = AS−i
C = CANopen
G = EtherNet/IP
P = PROFIBUS
R = PROFINET
S = standard I/O
T = EtherCAT
Connection system − communication and IO
N = NO BUS/standard IO: Terminal
A = communication: M12, IO: Terminal
9 = communication: M12, IO: M12
Drive−based safety
N = none
J = safety option 10 (safe torque off)
(incl. supplements IO)
Memory module
2 = for motec
Enclosure
P = IP65
E= IP66
Size
1 = 063 / 071
(E84DGDVB3714 ... 1124)
2 = 080 / 090 / 100 (E84DGDVB5514 ... 1524)
3 = 080 / 090 / 100 / 112 (E84DGDVB2224 ... 3024)
4 = 080 / 090 / 100 / 112 (E84DGDVB4024 ... 7524)
5 = 132 (E84DGDVB5524 ... 7524)
