23 Leica IP S
• Unscrew the 8 screws (2, Fig. 8 ) on the sides
of the wooden box and loosen the cover.
• Remove the accessory box (7, Fig. 9 ) including
accessories and packaging material) - directly
under the lid.
• Unscrew the 8 screws (3, Fig. 8 ) on the floor
of the wooden box on the exterior.
• Remove the interior carton around the instru-
ment.
• Carefully remove the wooden box from the
baseplate.
• The printer is secured with 4 plates (5) on
the wooden floor of the outside box. Loosen
the two screws (4, Fig. 10 ) on the base of the
instrument. Remove the plate from the bottom.
• Place the printer from the baseplate on a
stable laboratory bench - or, if present, on the
automated unload station. Make sure that the
stage is leveled!
Fig. 9
7
4
5
5
Fig. 10
When unpacking the printer, at least
two people (one person on each side
of the printer) are required to lift the
printer out of the box and place it onto
the laboratory bench.
Fig. 11
6
• If the instrument was set up at its final area of
use, remove the blue foam transport anchor
(6, Fig. 11 ) (pull upwards).
4. Instrument Setup
