Grader snow/dirt kit (option) – Landoll ICON 1632RS Grader User Manual
Page 58
6-34
F-740-1213 Edition
ILLUSTRATED PARTS LIST
Grader Snow/Dirt Kit (Option)
ITEM
PART NO.
DESCRIPTION
QTY.
179183
GRADER SNOW/DIRT KIT (OPTION)
1
1-512-010005-09
NUT, HEX LOCK 1/2-13 GRB
4
2
1-512-010005-19
NUT, HEX LOCK 1-8 GRB
1
3
1-654-010055-05
SCREW, HEX HEAD CAP 1/2-13 X 2 GR5
4
4
1-861-010032-14
WASHER, FLAT 1/2N
8
5
144264
BEARING, FLANGE 1”
2
6
155971
PIN, SPRING CLIP
1
7
172580
SCREW, HEX HEAD CAP 1-8 X 6 GR8
1
8
179184
GRADER SNOW/DIRT SKID WELDMENT
1
9
179187
GRADER SNOW/DIRT SKID WELDMENT
1
10
179190
GRADER SNOW/DIRT SKID WELDMENT
1
