Rear seedbox – Landoll BPSB6 Till-N Seed User Manual
Page 23
OPERATION
2-9
Rear Seedbox
• Rear Seedbox cups are adjusted just like the Front
Seedbox.
NOTES
Rear Seedbox Seed Cups discharge to the rear of the
machine.
Figure 2-9: Rear Seedbox Cups
Outer Seed Rate
Adjusting Nut
Inner Seed Rate
Adjusting Nut
Seed Shaft
Indicator
Indicator Scale
Seed Cup
Cut-off
Indicator
Mounting Hardware
Seed Cup Mounting
Hardware
Indicator must read "0"
when Seed Cups are closed
Small Seed Cup
Shaft moves to increase Seed Rate
Shaft moves to decrease Seed Rate
Rear Seedbox
Front
Seedbox
Front Box
Indicator
Wrenches
Rear Seedbox
Front
Seedbox
Rear Box
Indicator
Wrenches
