Data Sheet 706021 (706000) JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 3/11
Resistance transmitter and potentiometer input
DC voltage or current input
Response on transducer short-circuit/break
Recording system
Range Accuracy Measurement current
up to 130

up to 390

up to 1600

up to 3900

±150m

±300m

±1.6

±2

400
A
400
A
50
A
50
A
Connection type resistance transmitter: 3-wire circuit
potentiometer: 2-, 3- or 4-wire circuit
Shortest span 6

Sensor lead resistance max. 30
 per core in 3-wire circuit
max. 15
 per core in 2-wire circuit
Resistance values within the limits, freely programmable in 0.1  steps
Measurement time 240msec for all three channels
Input filter second-order digital filter; filter constant adjustable from 0 to 10.0sec
Basic range Accuracy Input resistance
-15 to +77mV
0 — 170mV
-76 to + 76mV
-162 to +880mV
0 — 1930mV
-880 to +880mV
-1.84 to +10V
0 — 22V
-10 to +10V
±80
V
±120
V
±120
V
±1mV
±1mV
±1mV
±6mV
±12mV
±12mV
>1M

>1M

>1M

>500k

>500k

>500k

>500k

>500k

>500k

Shortest span 5mV
Range start/end freely programmable within the limits
(up to 999mV in 0.01mV steps, above 1V in 1mV steps)
-4 to +21mA
0 — 45mA
-20.5 to +20.5mA
±20
A
±40
A
±40
A
Shortest span 0.5mA
Range start/end within the limits, freely programmable in 0.01mA steps
Measurement time 240msec for all three channels
Input filter second-order digital filter; filter constant adjustable from 0 — 10.0sec
Special features adjustable linearization for thermocouples and RTD temperature probes
(for connecting transmitters without linearization)
Short-circuit 1 Break 1
Thermocouple recognized recognized
RTD temperature probe recognized recognized
Resistance transmitter not recognized not recognized
Potentiometer recognized recognized
Voltage up to 170mV recognized recognized
Voltage above 170mV not recognized not recognized
Current 0mA is recognized 0mA is recognized
1. The fiber pens are positioned to 0%. “>>>>>>” appears in the LED dot matrix display.
Zero adjustment self-compensating system using Hall sensors
Drive stepping motor
Sensitivity 0.2% or better referred to 100mm recording width
Reproducibility 0.25% or better referred to 100mm recording width
Response time 1sec referred to 100mm recording width
Indication and recording accuracy Class 0.5 referred to range limits and basic ranges
Ink capacity sufficient for approx. 1000m trace; on channel 1 depending on text printing
Color sequence channel 1: blue, channel 2: red, channel 3: green
Pen offset 2mm; can be corrected by pen offset compensation
