Data Sheet 706021 (706000) JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 11/11
Order details
(1) Basic version
706021 LOGOLINE 500d with 1 universal input and text output
706022 LOGOLINE 500d with 2 universal inputs and text output (via channel 1)
706023 LOGOLINE 500d with 3 universal inputs and text output (via channel 1)
(2) Inputs 1 — 3 (programmable)
x x x 8 factory-set
x x x 9 configuration to customer specification
1
(3) Interface
x x x 00 not assigned
x x x 52 RS422, Jbus, Modbus
x x x 53 RS485, Jbus, Modbus
(4) Supply
x x x 22 20—53V AC/DC +0/-0% 48—63Hz
x x x 23 110—240V AC +10/-15% 48—63Hz
(5) Extra codes
x x x 020 lithium battery for RAM buffer (ex-factory)
x x x 021 storage capacitor for RAM buffer (instead of extra code 020)
x x x 259 8 logic inputs, interface for external relay module (ER8),
voltage output 24V 50mA DC
x x x 265 door with lock (IP54)
x x x 266 IP65 seal, wide fixing brackets
x x x 350 universal carrying case TG-35 2
x x x 351 housing with carrying handle 3
(1) (2) (3) (4) (5)
Order code / - - / , ... 4
Order example 706023 / 8 - 00 - 23 / 020
Accessories
Sales No.
Setup program, multilingual 70/00355073
PC interface with TTL/RS232 converter 70/00301315
PC interface with USB/TTL converter, adapter (socket) and adapter (pins) 70/00456352
Type 703564/1-23 ER8 relay module, 110 — 240V AC 70/00405292
Type 703564/1-22 ER8 relay module, 20 — 53V AC 70/00405297
Consumables
(Mindestbestellwert 100,00 EUR) Sales No.
Roll chart 16m (5 rolls) 70/00331497
Roll chart 32m (5 rolls) 70/00331499
Fanfold chart 15,6m (5 packs) 70/00331490
Fiber pen blue (2 pieces)) 70/00331664
Fiber pen red (2 pieces) 70/00331666
Fiber pen green (2 pieces) 70/00331667
1. Please specify probe types and measurement ranges in plain text.
2. This extra code is available in combination with supply voltage 110—240V AC, not with low supply voltage.
UL approval is not available. The protection type in the carrying case corresponds to IP20, outside IP20D.
3. UL approval is not available.
4. Extra codes are listed in sequence and separated by a comma.
