Data Sheet 706021 (706000) JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 2/11
Technical data
Thermocouple input
RTD temperature probe input
Designation Range Linearization accuracy
1
Fe-Con L DIN 43710
Fe-Con J EN 60584
Cu-Con U DIN 43710
Cu-Con T EN 60584
NiCr-Ni K EN 60584
NiCr-Con E EN 60584
NiCrSi-NiSi N EN 60584
Pt10Rh-Pt S EN 60584
Pt13Rh-Pt R EN 60584
Pt30Rh-Pt6Rh B EN 60584
-200 to +900°C
-210 to +1200°C
-200 to
+600°C
-270 to +400°C
-270 to +1372°C
-270 to +1000°C
-270 to +1300°C
-50 to +1768°C
-50 to +1768°C
0 — 1820°C
±0.1%
±0.1%
above -200°C
±0.1% above -150°C
±0.1% above -150°C
±0.1% above -80°C
±0.1% above -100°C
±0.1% above -100°C
±0.15% above 0°C
±0.15% above 0°C
±0.15% above 400°C
Shortest span Types L, J, U, T, K, E, N:
Types S, R, B: 100°C
500°C
Range start/end within the range limits, freely programmable in 0.1°C steps
Cold junction Pt 100 internal, external Pt 100 in 3-wire circuit
or external cold junction thermostat
Cold junction accuracy (internal) ± 1°C
Cold junction temperature (external) -20 to +100°C can be set via the setup program
Measurement time 240msec for all three channels
Input filter second-order digital filter; filter constant adjustable from 0 — 10.0sec
Special features programmable also in °F; customer-specific linearization
1. The linearization accuracy refers to the maximum measurement span.
Designation Connection Range Linearization accuracy Meas. current
Pt 100 DIN 2/3-wire
2/3-wire
4-wire
4-wire -200 to +100°C
-200 to +850°C
-200 to +100°C
-200 to +850°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 400
A
400
A
400
A
400
A
Pt 100 JIS 2/3-wire
2/3-wire
4-wire
4-wire -200 to +100°C
-200 to +649°C
-200 to +100°C
-200 to +649°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 400
A
400
A
400
A
400
A
Pt 500 DIN 2/3-wire
2/3-wire
4-wire
4-wire -200 to +100°C
-200 to +850°C
-200 to +100°C
-200 to +850°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 50
A
50
A
50
A
50
A
Pt 1000 DIN 2/3-wire
2/3-wire
4-wire
4-wire -200 to +100°C
-200 to +850°C
-200 to +100°C
-200 to +850°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 50
A
50
A
50
A
50
A
Ni 100 2/3-wire
2/3-wire
4-wire
4-wire -60 to +100°C
-60 to +180°C
-60 to +100°C
-60 to +180°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 400 A
400
A
400
A
400
A
Connection type 2-, 3- or 4-wire circuit
Shortest span 15°C
Sensor lead resistance max. 30
 per core in 3-wire circuit
max. 15
 per core in 2-wire circuit
Range start/end within the limits, freely programmable in 0.1°C steps
Measurement time 240msec for all three channels
Input filter second-order digital filter; filter constant adjustable from 0 — 10sec
Special features programmable also in °F; customer-specific linearization
