Dimensions – JUMO 706021 LOGOLINE 500d Line Recorder Data Sheet User Manual
Page 10
2010-06-21/00324162
Data Sheet 706021 (706000)
JUMO GmbH & Co. KG • 36035 Fulda, Germany
Page 10/11
Dimensions
Housing for
flush-panel mounting
Code 350
Portable recorder housing
for varying applications
in mobile use
Code 351
Housing with carrying
handle, rubber feet
and terminal cover, also
3m mains supply cable with
SCHUKO plug
373
326
366
226
314
