5 Dimensions

Varivent connection

Ball weld-in pocket

JUMO PEKA PA 997
Process connection adapter
see data sheet 409711

PA DN

D1

684 15/10

Ш 31

685 32/25

Ш 50

686 50/40

Ш 68

PA
840

Varivent

Clamp

Aseptic

Weld-in
socket

DN 25/32 DN 25/32/40 DN 40

Ø 55 mm

DN 40-125 DN 50

DN 50

-

-

-

NKS DN 40 -
