5 Dimensions
Weld-in ball socket
with clamping nipple Taper nipple
with cap nut
according to DIN 11851
(milk pipe fitting)
Weld-in socket
with CIP-compliant conical seal
PA
681 PA DN D1 D2 D3 D4 L1 L2
601 10 Ш 22 Ш 18 RD 28 Ч 1/8 Ш 38 9 18
604 25 Ш 44 Ш 35 RD 52 Ч 1/6 Ш 63 13 21
605 32 Ш 50 Ш 41 RD 58 Ч 1/6 Ш 70 13 21
28
EL
15
41
D
30 Ø
G1/2
18 Ø
PA
682
